Along with being displayed in an event table, seismic events can also be clearly displayed in seismic statistics.
In this version it is now also possible to display statistics for vector sums and Kbf values:
Version 5.4.2
08.12.2023
New features
- In the vibration statistics, the peaks of the vector sum and Kbf can now also be displayed, in addition to the peaks of the signal curve. It is then also possible to display the threshold values of the relevant standards (VSS 40312, ÖNORM, DIN 4150-2).
- The user-defined threshold values are now also displayed in the blast table
- Blasting operations can now be displayed in diagrams (background data)
- Setting up a Menhir device in a new project has been simplified. Previously, channel assignments could only be carried out once data had already been received. Now the device configuration is transmitted earlier, so that it is possible to create measuring points and assignments earlier.
Changed functions
- When displaying the trigger condition of events, the user-defined name of the recording profile is now also displayed in the menu.
Fixed bugs
- The export of a vibration measuring point via the Web API only provided time stamps without measured values.
- When carrying out visualization in web-based maps, the shape colors did not update according to the alert or online status of the measuring points.
- Under certain circumstances, deleting alert definitions failed.
